Software Defined Radio.
The latest development is a radio card plugged into a raspberry pi 3 , a so called rpi-hat, forming an amateur radio. Given the name 'Radioberry'.
The building blocks containg hardware and software components can be found @Radioberry-Repo.
The blogs learns you about the different possible configurations.
Radioberry Forum
Posted by: Johan Maas -
05/06/18 @ 7:06PM
Iam getting a lot of questions from radio amateurs about the radioberry.
Maybe a good place to share questions or hints is a google discussion forum.
https://groups.google.com/forum/#!forum/radioberry
Looking forward how this will workout.
73 Johan
PA3GSB
Quisk + RPI + Radioberry => Amateur radio
Posted by: Johan Maas -
19/05/18 @ 3:29PM
Quisk
I was already using quisk, running at a seperate computer using the hermes emulator.
Still wanted to use Quisk (quisk) running als at the rpi.
Did an install and the normal configuration, setting to small screen.
Starting quisk resulting in the followin...
Radioberry V2.0 beta 2
Posted by: Johan Maas -
18/02/18 @ 4:54PM
Radioberry V2.0 beta 2
The Intel Cyclone 10 FPGA chips finally arrived.
During the backorder time of the FPGA i decided to order 10 Radioberry V2.0 beta 2
cards @Makerfabs.
They created the PCB and did the PCBAssembly; looking real great!
Only the assembly of the Cyclone...
Radioberry pihpsdr cw-setup
Posted by: Johan Maas -
05/12/17 @ 7:37PM
Radioberry pihpsdr cw-setup
The following picture shows how all the components are working together to make cw work for the combination of radioberry and the pihpsdr software.
Hardware Setup
The dot and dash is connected to the J2 of the radioberry.
The fpga lines IO-15 and IO-16...
